Fiber Optical Splice Closure, In-Line, 8 Ports, 36 Fibers
Re-openable inline closure for outdoor splicing, branching and drop cable distribution.
Description
FOSC-H8 Series is an inline fiber optic splice closure for outdoor FTTH / FTTx cable branching and drop distribution. Its fully mechanical, re-openable design uses PP+GF housing and a vulcanized butyl rubber sealing strip for accessible installation and maintenance. The closure supports splicing, branching, adapter connections and splitter installation. SC adapter/drop cable ports accept figure drop cables, allowing fast connector access without opening the main body. The simple internal structure supports efficient installation at pole-mounted, wall-mounted and aerial distribution points. A valve and earthing rod are optional; cable dimensions, capacities and splitter/adapter configurations are listed below.
Key specifications
| Series Name | FOSC-H8 Series |
|---|---|
| Model Name | FOSC-H8 |
| Size | 318.5 × 238 × 118 mm |
| Housing Material | PP + GF |
| Max Splicing Capacity | 36F |
| Max Tray Number | 3 Trays |
| Tray Capacity | 12F Per Tray |
| Main Cable Ports | 2 Inlet + 2 Outlet Round Ports |
| Drop Cable Ports | 8 SC Adapter / Drop Cable Ports |
| Main Cable Diameter | Φ8–Φ12 mm |
| Drop Cable Size | 2 × 3 mm Figure Drop Cable |
| Splitter / Adapter Options | 2 pcs 1:4 / 2:4, or 1 pc 1:8 / 2:8 With SC-Sized Adapter |
| Sealing Method | Vulcanized Butyl Rubber Strip |
| Working Temperature | -40°C to +65°C |
| Atmospheric Pressure | 62–106 kPa |
| Axial Tension | >1000N / 1 min |
| Stretching Resistance | >2000N / 10 cm², 1 min |
| Flatten Pressure | >2000N / 100 mm, 1 min |
| Insulation Resistance | >2 × 104 MΩ |
| Voltage Strength | 15 kV DC / 1 min, no arc-over or breakdown |
| Optional Accessories | Valve / Earthing Rod |
Additional model reference
Fiber Optical Splice Closure 08
Model No.: FOSC-IL-08C
*Fixed with buckles, sealed with silicon, easy to open
*Small dimension, cable in & out from left and right, input from the base, easy installation and maintenance
*Easy to install and reopen, no need the special training
*Equipped with sizes of cable rings for kinds of cables in and out
*8 pcs fast connectors on the base, available 8 pcs cables output
*The 8 pcs of fusion fast connectors at the bottom can meet the requirement of maximum 8 pcs of optic fiber fast and straight fusion output at the same time
*1pc 1*8 splitter available.
| *Applicable cable diameter | 9-11mm |
|---|---|
| *Applicable environment | Aerial, pipe-lined |
| *L * W * H | 276*248*117.2mm |
| *Waterproof rate | IP65 |
Note: We have more difference model. Quotation based on customer photos
