Access Building Cable

Inquiry-first product detail for category-led browsing and B2B decision support.

Access Building Cable

Description

ASKA-ABC-* Access Building Cable is designed for indoor building access and FTTH distribution applications where a compact, lightweight, and flame-retardant fiber cable is required. The cable uses 250 µm optical fibers positioned inside a high-modulus PBT loose tube, filled with water-resistant tube filling compound, reinforced with aramid yarn, and finished with an LSZH low-smoke zero-halogen flame-retardant outer jacket. It is available in 2, 4, 6, 8, 12, and 24 fiber core configurations.

Key Specifications

Model No.	ASKA-ABC-*
Cable Type	Access Building Fiber Optic Cable
Fiber Count	2 / 4 / 6 / 8 / 12 / 24 Cores
Fiber Type	Single-Mode Fiber
Fiber Options	G.652D / G.657A1 / G.657A2
Fiber Size	250 µm
Loose Tube	High-Modulus PBT Loose Tube
Strength Member	Aramid Yarn
Outer Jacket	LSZH Flame-Retardant Jacket
Max Working Tension	200N / 660N
Crush Resistance	300N/100mm / 1000N/100mm
Bend Radius	Static 10D / Dynamic 20D
Operating Temperature	-40°C to +70°C

Cable Structure

Cable Structure Includes:

LSZH low-smoke zero-halogen outer jacket
PBT loose tube
250 µm optical fibers
Tube filling compound
Aramid yarn strength member
Compact, lightweight building-access structure
